LIGHTING HARDWARE

www.westinghouselighting.com

117

CARDED PRODUCT SOLD IN INNER PACK ONLY.

*

Bulk Pack

Medium

Porcelain Threaded Socket

with Aluminum Shade Ring

70010

Medium Base

Height - 15/8"

Ring Height - 1/2"

660 Watts Max.

250 Volts

MR16

Porcelain Socket

11107

5" Wire Leads

SF-1 200

°

C Leads

75 Watts Max., 125 Volts

Fits G5.3, GU5.3

and GX5.3 Lamp Bases

MR16

Porcelain Socket

11108

5" Wire Leads

SF-1 200° C Leads

75 Watts Max., 300 Volts

Fits G5.3, GU5.3

and GZ5.3 Lamp Bases

Porcelain

Halogen Socket

11104

5" Wire Leads

SF-1 200

°

C 300V Leads

100 Watts Max., 250 Volts

Fits G4, GX5.3, GV5.3

and G6.35 Lamp Bases, Height - 3/8"

Medium

Candelabra

Slimline Slide-On

Lamp Holder

22452

Fixed Pedestal-Type

Shallow End

For T8 Lamps

660 Watts Max., 1000 Volts

Medium BiPin Turn

Type Lamp Holder

22454

Low Profile Size

No. 18/20 Gauge

Panel Mount, Captive

Mount and Screw

660 Watts Max., 600 Volts

Non Shunted

Socket

Adapter Reducer

22402

Reduces German or

Italian Base to

Candelabra Size

With Rubber Ring

75 Watts Max., 120 Volts

Socket

Adapter Reducer

22403

Reduces Intermediate Base to

Candelabra Base

With Rubber Ring

75 Watts Max.

120 Volts

German

Intermediate

Candelabra

Candelabra

Porcelain 2-Piece

Sign Receptacle

22266

Medium Base

660 Watts Max., 250 Volts

Height - 11/2"

300° C Maximum Temp.

*

Porcelain

1-Piece Receptacle

22273

Medium Base

660 Watts Max., 600 Volts

Height - 11/2"

180° C Maximum Temp.

*

Porcelain Threaded Socket

with Steel Shade Ring

22272

70429

Medium Base

1/8-IP Bushing with Set Screw

Height - 21/8", Ring Size - 21/4"

660 Watts Max., 250 Volts

*

Porcelain Mogul

Base Socket with

3-Way Removable Knob

22281

1/4-IP Bushing

750 Watts Max., 250 Volts

Height - 41/4"

*

Porcelain Mogul

Base Socket

22282

1500 Watts Max., 600 Volts

Height - 25/8"

4 K.V. Pulse Rated

*

High Pressure

Sodium Lamp Socket

22481

9" Wire Leads

Medium Base

SF-2/SEW-2 200

°

Leads

4 K.V. Pulse Rated

660 Watts Max., 600 Volts

6/32 Bushing

Height - 13/4"

*

Mini BiPin Quartz

MR16 Socket

22471

GX5.3 Base

12" 18 Gauge Leads

SF-1 200

°

C Leads

100 Watts Max., 250 Volts

Height - 1"

*

High Pressure

Sodium Lamp Socket

22480

9" Wire Leads

Medium Base

SF-2/SEW-2 200

°

Leads

4 K.V. Pulse Rated

660 Watts Max., 600 Volts

6/32 Screw-Down

Height - 13/4"

*

*

*

*

*

*

Slimline Slide-On

Lamp Holder

22451

Plunger Pedestal-Type

Shallow End

For T8 Lamps

660 Watts Max., 1000 Volts

Stationary End

Lamp Holder

22490

For HO, VHO, SHO Lamps

660 Watts Max., 1000 Volts

Non Shunted

*

Medium BiPin Lamp Holder

Floating Action for

U-Shape Lamps

22457

Low Profile Size

20 Gauge

660 Watts Max., 600 Volts

Non Shunted

*

Medium BiPin

Lamp Holder

22453

Low Profile Size

660 Watts Max., 600 Volts

T8/T12 Non Shunted

*

Medium BiPin Turn

Type Lamp Holder

22456

Standard Size

No. 18/20 Gauge

Panel Mount

660 Watts Max., 600 Volts

Non Shunted

*

Plunger End

Lamp Holder

22491

For HO, VHO, SHO Lamps

660 Watts Max., 1000 Volts

Non Shunted

*

*

Porcelain Socket Extender

22150

70364

Medium Base

660 Watts Max., 250 Volts

Extension - 11/4"

Overall Length - 21/4"

*

*

*

Socket

Adapter Enlarger

22411

70361

Enlarges Candelabra Base

to Medium Base

75 Watts Max., 125 Volts

*

Medium

Mini BiPin Quartz

MR16 Socket

22470 - GY6.35 Base

22472 - GX5.3 Base

12" 18 Gauge Leads

SF-1 200

°

C Leads

100 Watts Max., 250 Volts

Height - 3/8"

*

*
