6
01250 & 0125011
Sidemount Plus Fan Box®
3 Knockouts for Conduit or Romex
2 Romex Clamps
Box Depth 1½"
Heavy Duty, 15.5 Cubic Inch Dual Mount* Electrical Box
Ideal for Remodel Applications
• Sidemount bracket is removable for easy replacement
of existing nail-on boxes without attic access
01240 & 0124011
Sidemount Plus Fan Box®
3 Knockouts for Conduit or Romex
2 Romex Clamps
Box Depth 2⅛"
Heavy Duty, 21.5 Cubic Inch Dual Mount* Electrical Box
Sidemount bracket is removable for easy replacement
Heavy Duty, 21.5 Cubic Inch Dual Mount* Electrical Box
Heavy Duty, 15.5 Cubic Inch Dual Mount* Electrical Box
Engineered Simplicity
Sidemount Plus Fan Box
®
*Dual Mount = Box is threaded for 8-32 (ideal for box covers and light weight fxtures) and 10-24 screws (ideal for heavier fxtures and fans).
Step 1
Mount bracket to joist
through 4" hole in sheetrock.
Step 2
Pull wire into box and remount
box to bracket.
Easy to Install through 4" Hole in Sheetrock
