LED LAMPS
18
3 Low Voltage (12V)
4 Approved for Damp Location
Footnotes
1 New Item
2 Dimmable
5 Approved for Wet Location
6 Indoor Application Only
7 Approved for Use in Totally Enclosed Fixtures
LINEAR
LAMPS
All Linear LED Lamps are UL Classified and NSF Certified. 96" T8
46" T5
48" T8
36" T8
24" T8
Energy
Used
(Watts)
Lamp
Base
Item
No. Footnotes Domestic Code
Master
Carton/
Inner
Pack
Package
Type
Equiv.
Incand.
Wattage
Color
Designation Finish
Light
Appearance
(Kelvin) CRI
Brightness
(Lumens)
Avg.
Rated
Hours MOL
T5 46" (DESIGNLIGHTS CONSORTIUM® QUALIFIED PRODUCT)
25 Mini BiPin 43788 �n 4 LED 25T5/46"/40 Direct Install 10 Sleeve T5 Cool White Frost 4000 82 3500 50000 46"
Mini BiPin 43789 � n 4 LED 25T5/46"/50 Direct Install 10 Sleeve T5 Daylight Frost 5000 82 3500 50000 46"
Mini BiPin 50800� n 1,4,7 LED 25T5/46"/40 Ballast Bypass 25 Sleeve T5 Cool White White 4000 80 3300 50000 46"
Mini BiPin 51530 �n 1,4,7 LED 25T5/46"/50 Ballast Bypass 25 Sleeve T5 Daylight White 5000 80 3400 50000 46"
T8 24" (DESIGNLIGHTS CONSORTIUM® QUALIFIED PRODUCT)
8 Med. BiPin 50390 � 4,7 LED 8T8/24"/35 Direct Install 10 Sleeve T8 Cool White Frost 3500 82 1200 50000 24"
Med. BiPin 50250 � 4,7 LED 8T8/24"/40 Direct Install 10 Sleeve T8 Cool White Frost 4000 82 1250 50000 24"
Med. BiPin 50400 � 4,7 LED 8T8/24"/50 Direct Install 10 Sleeve T8 Daylight Frost 5000 82 1250 50000 24"
9 Med. BiPin 50430 � 4,7 LED 9T8/24"/35 Ballast Bypass 10 Sleeve T8 & T12 Cool White Frost 3500 82 1100 50000 24"
Med. BiPin 50260 � 4,7 LED 9T8/24"/40 Ballast Bypass 10 Sleeve T8 & T12 Cool White Frost 4000 82 1150 50000 24"
Med. BiPin 50440 � 4,7 LED 9T8/24"/50 Ballast Bypass 10 Sleeve T8 & T12 Daylight Frost 5000 82 1150 50000 24"
T8 36"
10 Med. BiPin 50421 4,7 LED 10T8/36"/50 Direct Install 10 Sleeve T8 Daylight Frost 5000 82 1450 50000 36"
10.5 Med. BiPin 50410 4,7 LED 10.5T8/36"/35 Direct Install 10 Sleeve T8 Cool White Frost 3500 82 1400 50000 36"
Med. BiPin 50270 4,7 LED 10.5T8/36"/40 Direct Install 10 Sleeve T8 Cool White Frost 4000 82 1450 50000 36"
12 Med. BiPin 50280 � 4,7 LED 12T8/36"/40 Ballast Bypass 10 Sleeve T8 & T12 Cool White Frost 4000 82 1450 50000 36"
Med. BiPin 50460 � 4,7 LED 12T8/36"/50 Ballast Bypass 10 Sleeve T8 & T12 Daylight Frost 5000 82 1450 50000 36"
T8 48" (DESIGNLIGHTS CONSORTIUM® QUALIFIED PRODUCT)
12 Med. BiPin 43851 � ◗ 4,7 LED 12T8/48"/DIM/35 Direct Install 10 Sleeve T8 Cool White Frost 3500 82 1700 50000 48"
Med. BiPin 43739 �◗ 4,7 LED 12T8/48"/DIM/40 Direct Install 10 Sleeve T8 Cool White Frost 4000 82 1800 50000 48"
Med. BiPin 43852 �◗ 4,7 LED 12T8/48"/DIM/50 Direct Install 10 Sleeve T8 Daylight Frost 5000 82 1800 50000 48"
15 Med. BiPin 53652 �◗ 4,7 LED 15T8/48"/DIM/35 Direct Install 10 Sleeve T8 Cool White Frost 3500 82 2100 50000 48"
Med. BiPin 43653 � 4,7 LED 15T8/48"/40 Direct Install 10 Sleeve T8 Cool White Frost 4000 82 2200 50000 48"
Med. BiPin 53655 �◗ 4,7 LED 15T8/48"/DIM/50 Direct Install 10 Sleeve T8 Daylight Frost 5000 82 2200 50000 48"
T8 48" SINGLE ENDED/DOUBLE-ENDED POWERED (DESIGNLIGHTS COSORTIUM® QUALIFIED PRODUCT)
14.5 Med. BiPin 51550 � 1,4,7 LED 14.5T8/48"/35 SE/DE Ballast Bypass 10 Sleeve T8 & T12 Cool White Frost 3500 83 1725 50000 48"
Med. BiPin 51560 � 1,4,7 LED 14.5T8/48"/40 SE/DE Ballast Bypass 10 Sleeve T8 & T12 Cool White Frost 4000 83 1750 50000 48"
Med. BiPin 51570 � 1,4,7 LED 14.5T8/48"/50 SE/DE Ballast Bypass 10 Sleeve T8 & T12 Daylight Frost 5000 83 1800 50000 48"
17 Med. BiPin 51420 � 1,4,7 LED 17T8/48"/35 SE/DE Ballast Bypass 10 Sleeve T8 & T12 Cool White Frost 3500 83 2050 50000 48"
Med. BiPin 51430 � 1,4,7 LED 17T8/48"/40 SE/DE Ballast Bypass 10 Sleeve T8 & T12 Cool White Frost 4000 83 2100 50000 48"
Med. BiPin 51440 � 1,4,7 LED 17T8/48"/50 SE/DE Ballast Bypass 10 Sleeve T8 & T12 Daylight Frost 5000 83 2200 50000 48"
T8 96"
43 Single Pin 04051 � 4,7 LED 43T8/96"/40 Ballast Bypass 10 Bulk T8 & T12 Cool White Frost 4000 82 5500 50000 96"
Single Pin 04052 � 4,7 LED 43T8/96"/50 Ballast Bypass 10 Bulk T8 & T12 Daylight Frost 5000 82 5500 50000 96"
� DLC Qualified
n Replace F54T5HO linear fluorescent lamps.
◗ Dimmable when used with a compatible dimming ballast.
Ballast Bypass lamps are designed to operate on voltages ranging from 120-277V.
See individual product specification sheets for dimmer and ballast compatibility on www.westinghouselighting.com.
